Group Eleven Intersects 7.24 metres of 23.9% Zinc, 6.6% Lead (30.5% Combined), 108 g/t Silver and 0.12% Copper in follow-up drilling at Carrickittle Prospect in Ireland
Vancouver, Canada, December 9th, 2020 - Group Eleven Resources Corp. (TSX.V: ZNG; OTC: GRLVF; FRA: 3GE) (“Group Eleven” or the “Company”) is pleased to announce results from Phase 1 follow-up drilling at the Carrickittle zinc prospect (“Carrickittle”) at the Company’s 100%-interest PG West project (“PG West”) in the Republic of Ireland.
- Top three zinc-lead intersections from follow-up drilling at Carrickittle are as follows:
- 7.24 metres of 23.9% zinc, 6.6% lead (30.5% combined), 108 g/t silver and 0.12% copper, including 5.20 metres of 32.2% zinc, 8.7% lead (40.9% combined), 144 g/t silver and 0.13% copper in G11-2840-09, including massive sulphide (true width is approximately 60%)
- 5.35 metres of 11.6% zinc, 2.4% lead (14.0% combined), 29 g/t silver in G11-2840-10, including massive sulphides (true width is approximately 80%)
- 3.00 meters of 4.8% zinc and 6.0% lead (10.8% combined), 35 g/t silver in G11-2840-12, including massive sulphides (true width is approximately 100%)
- High silver values were also intersected with 1.00 metres of 736 g/t silver in G11-2840-11 (true width is approximately 100%)
- The above follow-up drilling follows G11-2840-04 (announced July 6th, 2020) which intersected 10.30 metres of 14.6% zinc, 5.0% lead (19.6% combined) and 43 g/t silver
- In total, eight (8) holes (769 metres) were completed as part of Phase 1 of follow-up drilling at Carrickittle, focused on Zone 1 of the prospect
- Phase 1 drill results, coupled with historic intercepts, now show two parallel bodies of massive sulphide and vein-hosted mineralization, striking in a north-west orientation, with a currently-drilled strike length of over 100 metres each, a down-dip extent of approximately 10-30 metres each and a true thickness of approximately 3-7 metres and 1-3 metres, respectively
- The bodies remain open for expansion along strike to the northwest and to a limited degree to the southeast, with further follow-up drilling strongly warranted
“Not only did follow-up drilling at Carrickittle yield impressive high-grade mineralization over significant widths, but, even more importantly, we have now determined the true orientation of the high-grade massive sulphide lenses,” stated Bart Jaworski, CEO. “This provides us with a powerful template for tracing mineralization further along strike at Zone 1 and for future drilling at Zones 2, 3 and 4, immediately to the southwest at Carrickittle.”
PG West Zinc Project (100%-interest), Ireland
Carrickittle is hosted within the Company’s 100%-owned PG West project in southwestern Ireland. PG West is situated within the Limerick basin, a geological feature which also hosts the Company’s contiguous 76.56%-owned Stonepark project and Glencore’s adjacent Pallas Green project (hosting the Pallas Green zinc-lead deposit1; see Exhibit 1).
Exhibit 1. Location of Carrickittle Prospect at the Company’s 100%-owned PG West Project, Ireland
Notes to Exhibit 1: (a) Pallas Green MRE is owned by Glencore; (b) the historic estimate at Denison was reported by Westland Exploration Limited in 1988, the historic estimate at Tullacondra was reported by Munster Base Metals Ltd in 1973 and the historic estimate at Gortdrum was reported by G.M. Steed in 1986; these three historic estimates have not been verified as current mineral resources; none of the key assumptions, parameters and methods used to prepare the historic estimates were reported and no resource categories were used; significant data compilation, re-drilling and data verification may be required by a Qualified Person before the historic estimates can be verified and upgraded to be compliant with current NI 43-101 standards; a Qualified Person has not done sufficient work to classify them as a current mineral resource and the Company is not treating the historic estimates as current mineral resources.
Drilling at Carrickittle Prospect at PG West Project, Ireland
Eight holes totalling 769 metres were completed as part of Phase 1 of follow-up drilling at Carrickittle (see Exhibit 2, 4 and 10). All but one hole intersected meaningful zinc-lead mineralization.
Exhibit 2. Key Assays from Follow-Up Drilling at Zone 1 of Carrickittle Prospect, PG West Project, Ireland
|m x %
Note: As a percent of the drilled interval, true thickness is estimated to be 100% (for holes -11 and -12), 80-100% (-05, -07), 80% (-06, -10) and 60% (-09); “ZnEq” combines Zn, Pb, Cu and Ag into a single number and is calculated from metal prices (US$) as follows: $1.00/lb Zn, $1.00/lb Pb, $15.00/oz Ag and $3.00/lb Cu;
The strongest mineralization was intersected in G11-2840-09 which returned 7.24 metres of 23.9% zinc, 6.6% lead (30.5% combined), 108 g/t silver and 0.12% copper (see Exhibit 3). True widths are estimated to be approximately 60% of the drilled interval. This zone includes a down-hole width of 5.20 metres of massive sulphides grading 32.2% zinc and 8.7% lead (40.9% combined), 144 g/t silver and 0.13% copper. The highest grading portion of the massive sulphides returned 2.0 metres of 40.9% zinc and 12.7% lead (53.6% combined), 149 g/t silver and 0.11% copper.
Phase 1 drill results were also noteworthy due to the presence of locally elevated copper and silver within the mineralized zones. The highest copper intersected was 0.60% copper over 0.24 metres in G11-2840-09, within the wider 7.24 metre interval (described above) which averaged 0.12% copper. In terms of silver, G11-2840-11 returned a high-grade interval of 736 g/t silver over 1.00 metres. An additional assay of the original sample submitted to the lab was carried out as a check and returned 810 g/t Ag.
Exhibit 3. Table of Drill Results from G11-2840-09 at Carrickittle, PG West Project, Ireland
|19.35||0.65||35.90||9.97||45.87||153.0||0.13||49.62||Mostly massive sulphide|
|24.55||0.95||2.29||1.86||4.15||11.6||0.01||4.44||Altered dyke and WL|
|18.26||7.24||23.87||6.64||30.51||107.9||0.12||33.22||Entire interval (incl. cavity)|
|19.35||5.20||32.21||8.72||40.93||143.7||0.13||44.47||Massive sulphide and margins|
|21.00||2.00||40.90||12.65||53.55||148.5||0.11||57.12||Highest-grade massive sulphide|
Note: As a percent of the drilled interval, true width of mineralization is estimated to be 60%; “ZnEq” combines Zn, Pb, Ag and Cu into a single number and is calculated from metal prices (US$) as follows: $1.00/lb Zn, $1.00/lb Pb, $15.00/oz Ag and $3.00/lb Cu; “WL” = Waulsortian limestone;
Exhibit 4. Drill Hole Plan View of Carrickittle Prospect, Showing Newly Interpreted Mineralized Zones
Phase 1 drill results, coupled with historic intercepts, now clearly indicate two parallel bodies of massive sulphide and vein-hosted mineralization (‘Main Lens’ and ‘Lens Two’ on section A-A’ and B-B’, respectively, in Exhibit 4) striking in a north-west orientation, with a currently-drilled strike length of over 100 metres each, a down-dip extent of approximately 10-30 metres each and a true thickness of approximately 3-7 metres and 1-3 metres, respectively.
The mineralized lenses plunge (deepen) towards the northwest (see Exhibit 5 and 6) and dip (are tilted) sub-vertically (see Exhibit 7 and 8). Looking end-on, the lenses can be generally described as having thicker, generally flat-lying mineralization (commonly massive sulphide consisting of sphalerite, galena and pyrite) near the base, with lower grade and narrower vein-hosted mineralization (generally sub-vertical and striking north-west) near the top of the mineralized zone.
It is interpreted that mineralization in G11-2840-11 and G11-2840-12 likely intersected the thinner top of the mineralized zone and that a thicker zone of mineralization may occur directly below these intercepts.
Exhibit 5. Long-Section (A-A’) along Main Lens at Carrickittle, PG West Project, Ireland
Exhibit 6. Long-Section (B-B’) along Lens Two at Carrickittle Prospect, PG West Project, Ireland
In addition to variability of thickness in a vertical direction, there also appears to be variability along strike. Given its higher level of drilling and pierce points, the Main Lens exhibits this variability most prominently. Two wider zones appear to be connected by a narrower zone (i.e. exhibiting a possible pinch and swell geometry; see Exhibit 4).
Given the above geometric variability, the task of determining a true width is in some cases quite difficult. An example of this is G11-2840-10 (see Exhibit 6), where true width may range from 80% to 100% or lower, based on the shape of the zone assumed.
Both the Main Lens and Lens Two remain open for expansion along strike to the northwest, whereas, Lens Two is also open, albeit to a limited degree, to the southeast (see Exhibit 6). An area of particular interest on Lens Two is where the zone shallows towards surface and is interpreted to approach the apex of the intrusive dyke.
Phase 1 drill results suggest a close association of zinc-lead mineralization with intrusive activity as evidenced by close spatial proximity, but also the presence of zinc-lead mineralization hosted locally within the intrusive dykes.
Exhibit 7. Cross-Section (C-C’) Across Main Lens and Lens Two at Carrickittle, PG West Project, Ireland
The above cross-section (Exhibit 7) shows Group Eleven’s drilling which suggests (at least on this section) that the Main Lens and Lens Two are not connected (see G11-2840-08 and G11-2840-10). This section also shows the irregular shape of the lenses, its sub-vertical component and the fact the lenses tend to be thickest at the base and narrowest at the top. The mineralized bodies are spatially associated with inferred fault structures. Local intrusive activity (dykes) is also likely fault controlled. There appears potential to extend Lens Two (eastern-most) towards the east with further drilling.
Exhibit 8. Cross-Section (D-D’) Across Main Lens at Carrickittle Prospect, PG West Project, Ireland
The above section (Exhibit 8) shows the strongest intercept within the entire Phase 1 follow-up program (see G11-2840-09). Close proximity to the intrusive dyke is noted, along with a historic intercept of 0.8 metres of 8.3% zinc and lead within the dyke.
Next Steps and Outlook
Overall, Phase 1 follow-up drilling at Carrickittle has been successful in vastly increasing the Company’s understanding of the extent and nature of mineralization at Carrickittle. Specifically, drilling has demonstrated continuity of mineralization and shown the orientation of the mineralized trends. This information will be invaluable for further exploration at Zone 1, as well as, the start of modern exploration at Zones 2, 3 and 4 (see Exhibit 9), where impressive historic intercepts have not been re-visited since the mid-1960s. Further close-spaced drilling at Carrickittle is strongly warranted.
Exhibit 9. Plan Map of Zones 1, 2, 3 and 4 at Carrickittle Prospect, PG West Project, Ireland
|Hole ID||Dip°||Azimuth°||Total Depth (m)|
Quality Assurance / Quality Control (QA/QC)
Drill-core samples were prepared and assayed in the ALS Minerals Laboratory in Loughrea, Ireland. Samples were fine-crushed (CRU-31) to 70% < 2mm and pulverized and riffle-split to 85% < 75 µm. Zinc, lead and silver assays were obtained by multi-acid (4-acid) digestion/ICP-MS Package (48 Elements), with ore-grade samples. Analytical accuracy and precision are monitored by the submission of four standards and four blanks inserted into the sample train of 108 samples by Group Eleven personnel. No duplicate samples were sent to the lab. ALS analysed twenty-five blanks, fifteen duplicates and sixty-eight standards as part of their internal QC procedures.
Technical information in this news release has been approved by David Furlong, P.Geo., Chief Operating Officer, and ‘Qualified Person’ as defined under Canadian National Instrument 43-101.
About Group Eleven Resources
Group Eleven Resources Corp. (TSX.V: ZNG; OTC: GRLVF and FRA: 3GE) is a mineral exploration company focused on advanced stage zinc exploration in Ireland. Additional information about the Company is available at www.groupelevenresources.com.
ON BEHALF OF THE BOARD OF DIRECTORS
Bart Jaworski, P.Geo.
Chief Executive Officer
Neither TSX Venture Exchange nor its Regulation Services Provider (as that term is defined in the policies of the TSX Venture Exchange) accepts responsibility for the adequacy or accuracy of this release.
Cautionary Note Regarding Forward-Looking Information
This press release contains forward-looking statements within the meaning of applicable securities legislation. Such statements include, without limitation, statements regarding the future results of operations, performance and achievements of the Company, including the timing, content, cost and results of proposed work programs, the discovery and delineation of mineral deposits/resources/ reserves and geological interpretations. Although the Company believes that such statements are reasonable, it can give no assurance that such expectations will prove to be correct. Forward-looking statements are typically identified by words such as: believe, expect, anticipate, intend, estimate, postulate and similar expressions, or are those, which, by their nature, refer to future events. The Company cautions investors that any forward-looking statements by the Company are not guarantees of future results or performance, and that actual results may differ materially from those in forward looking statements as a result of various factors, including, but not limited to, variations in the nature, quality and quantity of any mineral deposits that may be located. All of the Company's public disclosure filings may be accessed via www.sedar.com and readers are urged to review these materials, including the technical reports filed with respect to the Company's mineral properties.
1 Resources and Reserves Report (Glencore, December 31, 2019) – 45.4 million tonnes of 7% Zn + 1% Pb (Inferred)
